OJT Equipment Foundation Design For Oil Gas/Industrial Plant (AFES)

Part of the OJT Civil Engineer Complete Package · 2 OJT Trainings

For : Civil Engineering

AFES training: design foundations for towers, heat exchangers and tanks on real projects.

4 trainings · 37 lessons · 100% online
Mentor: Heru Prasadja, ST - Senior Civil Engineer

OJT Equipment Foundation Design For Oil Gas/Industrial Plant (AFES)
Download Brochure See Packages

About this OJT

Learn straight from real projects with OJT Equipment Foundation Design For Oil Gas/Industrial Plant (AFES)

One of the tasks of a Civil Engineer in an oil refinery construction project is to design foundations for all process equipment in the oil refinery, such as Distillation Towers, Heat Exchangers, Storage Tanks, etc.

This OJT aims to train participants to be able to design the three most common types of equipment foundations found in oil refineries, namely Vertical Vessel Foundations, Horizontal Vessel Foundations, and Storage Tank Designs, in accordance with the design standards and specifications applicable in oil and gas projects.

During the design process, participants will use software commonly used in oil and gas projects, namely AFES.

Curriculum

What you'll learn

4 trainings · 37 lessons. Tap each part to see its lessons.

Training 1 Foundation Theory 10 lessons
  1. Stability Check
  2. Overturning
  3. Sliding
  4. Upending
  5. Soil bearing
  6. Strength Check
  7. One Way Shear
  8. Two Way Shear
  9. Pier Reincforcement Bar
  10. Slab Reinforcement Bar
Training 2 Equipment Foundation Computer Modelling (AFES) 18 lessons
  1. Define Project
  2. Input Parameter
  3. Allowable Stress And Unit Weight Of Material
  4. Concrete Cover
  5. Safety Factor
  6. Soil Bearing Capacity
  7. Single Pile Capacity
  8. Input Node & Dimension
  9. Input Reinforcement Bar
  10. Define Loading
  11. Dead Load
  12. Equipment Load
  13. Wind Load
  14. Seismic Load
  15. Define Unfactored Load Combination
  16. Define Factored Load Combination
  17. Setting Anchor
  18. Pile Arrangement
Training 3 Analysis Result 6 lessons
  1. Foundation & Pile Arrangement Illustration
  2. Pile Arrangement
  3. Safety Factor Of Pile
  4. Check Of Pile Capacity
  5. Shear Strength Check
  6. Reinforcement Design
Final Project Final Project 3 lessons
  1. Foundation Design for HP Amonia Scruber 124-D (Vertical Vessel)
  2. Foundation Design for Production Separator 31-MDB-101 (Horizontal Vessel)
  3. Foundation Design for Methanol Distilation Column 6160C1

How It Works

From first lesson to certificate

See the 7 learning steps

  1. Download all videos and materials from the links provided.

  2. Watch all tutorial videos and practice again.

  3. Complete the final assignment.

  4. Submit the assignment file for feedback.

  5. Make corrections if there is feedback for improvement.

  6. If the modeling assignment is correct, submit it in the form of a Calculation Report in the format provided.

  7. The certificate will be issued.

Choose a package

Complete Package Best value

OJT Civil Engineer Complete Package

The right choice if your goal is to work as Civil Engineer: no skill left behind, one single payment.

2 OJT Trainings at once: every skill you need to work as Civil Engineer.

  1. Steel Structure Design for Oil Gas Plant (STAAD PRO) Rp 1.750.000
  2. Equipment Foundation Design For Oil Gas/Industrial Plant (AFES) this OJT Rp 1.750.000

Rp 3.500.000 Rp 3.000.000 Save Rp 500.000 (14%)

Get the Complete Package
